▼ FEATURES & BENEFITS ▼
◆ RJ-45 Port Support Auto MDI/MDI-X Function
◆ Back-plane (Switching Fabric): 40 Gbps
◆ 16K MAC address table
◆ IPv6 management
◆ IEEE 802.1d Spanning Tree , IEEE 802.1w RSTP & IEEE 802.1s MSTP
◆ IGMP with Snooping and Query mode for Multi Media Application
◆ Port Based VLAN, 802.1Q Tag VLAN, GVRP
◆ SNMP Trap
• Device cold start, Power status, Authentication failure, Ring changed, Port Link up/Link down.
◆ SNTP for time sync
◆ TFTP Firmware Update & System Configure Restore/Backup
◆ Port Trunk with LACP
◆ Supports IEEE 802.1ab LLDP
◆ Supports IEEE 802.1p CoS, 4 priority queues per port
◆ Port base, Tag Base and Type of Service Priority
◆ Supports Ingress Packet Filter and Egress Rate Limit
◆ Supports Broadcast/Multicast Packet Filter Control
◆ Port Mirror: Monitor traffic in switched networks
• TX, RX, Both of TX and RX Packet
◆ Security
• Port Security: MAC address entries/Filter/MAC violation
• Denial-of-Service(DOS)Prevention
• IP Source Guard
• Loop Protection: prevents network attack, loopback cable detection and Miss-wiring avoidance
◆ Factory reset bottom can restore all setting back to factory default and Watchdog design to automatically reboot switch under certain circumstances.
▼ IEEE Standards ▼
◆ IEEE802.3 10Base-T Ethernet
◆ IEEE802.3u 100Base-TX
◆ IEEE802.3ab 1000Base-T
◆ IEEE802.3z Gigabit fiber
◆ IEEE802.3x Flow Control and Back Pressure
◆ IEEE802.3ad Port trunk with LACP
◆ IEEE802.3af Power over Ethernet
◆ IEEE802.1d Spanning Tree
◆ IEEE802.1w Rapid Spanning Tree
◆ IEEE802.1s Multiple Spanning Tree
◆ IEEE802.1p Class of Service
◆ IEEE802.1Q VLAN Tag
◆ IEEE802.1ab LLDP
◆ IEEE802.3az Power Saving
* 產品規格若有變更,恕不另行通知。
