▼ Key Features ▼
◆ 3-axis joystick for handy PTZ control
◆ user-friendly button placement and LCD display for instant operation
◆ shattering the market with the exclusive “Mouse Mode”
◆ two-level jog shuttle with variable speed control
◆ controls up to 255 PTZ cameras via an RS-485 interface
◆ 1 built-in microphone and 1 audio output for easy installation
◆ supports PTZ protocol: Pelco-P and Pelco-D
◆ lock protection to prevent unauthorized operation
◆ USB upgrade available for future updates
◆ compatible with CM3000/CM3000 Gold
▼ Live monitoring operation ▼
◆ change live display layout to the 1/4/8/9/13/16/32-screen configuration
◆ able to select channels for display of detailed settings
◆ start/stop channel auto scan during live monitoring
◆ adjust audio volume
◆ digital zoom for selected areas of live video
◆ switch to full screen mode
▼ Camera operation ▼
◆ camera connection and display settings
◆ configures hue/brightness/saturation/contrast of camera
◆ de-interlace mode setting
◆ trigger IP camera (network camera) relay output
▼ Playback operation ▼
◆ two-level jog shuttle to move forward and backward at various speeds
◆ play/pause button
▼ PTZ operation ▼
◆ connect to PTZ through DVR or RS-485 interface directly
◆ auto pan/IRIS/manual focus control
◆ PTZ preset points setting available
▼ General operation (AVer Windows® based DVRs/NVRs) ▼
◆ start system recording
◆ enable DVR network connection
◆ snapshot
◆ trigger alarm
◆ alarm/event log
* Specifications are subject to change without prior notice.
